BenchPress

Press a button. Get a Frappe bench. Self-hosted, Docker-powered, VPN-secured.

A self-hosted alternative to Frappe Cloud, built entirely as a Frappe app.

What is BenchPress?

Getting Started -- Installation and first setup
Creating Labs & Deploying -- Labs, builds, and deployments
Connecting to Benches -- SSH, VPN, and connection info
Logs & Monitoring -- Build logs, deploy logs, and stats
VPN Device Management -- Register devices for WireGuard access
WireGuard Setup -- Detailed WireGuard configuration

The Problem

Setting up a Frappe/ERPNext development environment is painful:

Manual setup -- Install bench CLI, MariaDB, Redis, Node.js, wkhtmltopdf, and a dozen other dependencies
Dependency conflicts -- Different projects need different Frappe versions and your OS gets polluted
No isolation -- One broken bench can affect everything on your machine
No remote access -- Team members cannot SSH into each other's dev environments
Repetitive work -- Every new project means repeating the same 30-minute setup ritual

There is no simple way to say "Give me a fresh Frappe bench with ERPNext and HRMS" and have it running in minutes.

The Solution

BenchPress is a self-hosted Frappe Cloud alternative built entirely as a Frappe app. It automates the entire bench lifecycle through a modern web UI:

Create a Lab -- Define a reusable template with your desired Frappe apps (CRM, ERPNext, HRMS, LMS, Helpdesk, Wiki, etc.), the Frappe version, and resource limits (CPU, memory)
Build once -- Docker image with all apps baked in via a 5-layer cached Dockerfile, rebuilt only when configuration changes
Deploy in clicks -- Each bench runs in its own Docker container with MariaDB, Redis, SSH, and all services included
SSH via WireGuard -- Secure kernel-level VPN access into any container, no exposed ports on the public internet
Real-time logs -- Watch Docker image builds and container deployments stream live in the browser via WebSocket
Manage everything -- Start, stop, restart, delete benches. Create multiple Frappe sites per bench. Monitor CPU and memory usage in real time.

Architecture

                                +---------------------------+
                                |       User's Browser      |
                                |  Vue 3 SPA (frappe-ui)    |
                                +-------------+-------------+
                                              |
                                     HTTPS / WebSocket
                                              |
                                +-------------v-------------+
                                |      Frappe Web Server     |
                                |  (BenchPress Frappe App)   |
                                |                            |
                                |  api.py ---- REST API      |
                                |  hooks.py -- Scheduler     |
                                |  wg_manager -- WireGuard   |
                                +---+--------+----------+---+
                                    |        |          |
                     +--------------+   +----v----+  +--v--------------+
                     |                  |  Redis   |  | deploy_manager  |
                     |                  |  Queue   |  | (Background     |
                     |                  |  (RQ)    |  |  Workers)       |
                     |                  +----+-----+  +--+---------+---+
                     |                       |           |         |
              +------v------+         +------v------+    |   +-----v--------+
              |  WireGuard  |         |   Docker    |<---+   | stats_       |
              |  (wg0)      |         |   Engine    |        | collector    |
              |  10.10.0.0  |         |   (SDK)     |        | (cron 2min) |
              |  /24 subnet |         +------+------+        +--------------+
              +------+------+                |
                     |              +--------v---------+
                     |              |  benchpress       |
                     |              |  Docker Network   |
                     |              |  172.30.0.0/24    |
                     |              +---+-----+-----+--+
                     |                  |     |     |
                 DNAT Routing     +-----v-+ +-v---+ +v-------+   +------------------+
                 (iptables)       | Bench | |Bench| | Bench  |   | benchpress-      |
                 22,8000,9000     | Ctr 1 | |Ctr 2| | Ctr N  +-->| mariadb          |
                     |            |       | |     | |        |   | (shared MariaDB) |
                     +----------->| SSH   | |SSH  | | SSH    |   +------------------+
                                  | Frappe| |Frapp| | Frappe |
                                  +---+---+ +--+--+ +---+----+   +------------------+
                                      |        |        |         | benchpress-      |
                                      +--------+--------+-------->| redis            |
                                                                  | (shared Redis)   |
                                                                  +------------------+

How the Pieces Fit Together

Component	Role
Frappe Web Server	Hosts the BenchPress app, serves the Vue 3 SPA, handles REST API calls, and publishes real-time WebSocket events
Redis Queue (RQ)	Processes long-running background jobs: Docker image builds (up to 60 min) and container deployments
Docker Engine	Builds images from the 5-layer Dockerfile template, creates and manages containers with CPU/memory limits
WireGuard (wg0)	Kernel-level VPN on the host. Each bench gets a unique IP (10.10.0.X). iptables DNAT rules route ports 22, 8000, and 9000 from the WG IP to the container
Shared MariaDB	A `benchpress-mariadb` container shared across all benches, managed via `docker-compose.yml`. Each site gets its own database (named by SHA1 hash). Managed via the Database Server DocType
Shared Redis	A `benchpress-redis` container shared across all benches. DB 0 = cache, DB 1 = queue, DB 2 = socketio. Also managed via `docker-compose.yml` with `restart: always`
Stats Collector	Cron job running every 2 minutes that polls Docker stats API for all running containers and updates CPU/memory metrics
Each Container	A Frappe bench with SSH server and all pre-installed apps. MariaDB and Redis are provided by the shared containers. Users SSH in and run `bench start`

Container Lifecycle

  CREATE LAB            BUILD IMAGE              DEPLOY BENCH                ACCESS
  (Template)           (Docker Build)          (Container + VPN)          (SSH + Web)
 +-----------+     +------------------+     +---------------------+     +-------------+
 |           |     |                  |     |                     |     |             |
 | Lab ID    |     | Layer 1: apt     |     | 1. Check image      |     | WireGuard   |
 | Frappe v  +---->| Layer 2: SSH     +---->| 2. Ensure shared    +---->| client .conf|
 | Apps[]    |     | Layer 3: bench   |     |    MariaDB + Redis  |     |             |
 | CPU/Mem   |     | Layer 4: apps    |     | 3. Create container |     | ssh frappe@ |
 |           |     | Layer 5: site    |     | 4. Setup WireGuard  |     | 10.10.0.X   |
 |           |     |                  |     | 5. Set SSH password |     |             |
 +-----------+     +------------------+     +---------------------+     +-------------+
   Status:            Cached layers            Logs streamed via          Ports:
   Draft              rebuild only             WebSocket in               22   -> SSH
                      when config              real-time                  8000 -> Web
                      changes                                             9000 -> Socket.io

Tech Stack

Layer	Technology	Purpose
Backend	Python 3.14 + Frappe Framework v16	REST API, background jobs, ORM, permissions
Frontend	Vue 3 + Vite + TailwindCSS + frappe-ui	Modern SPA dashboard with real-time updates
Containers	Docker Engine (Python SDK)	Image builds, container lifecycle, resource limits
VPN	WireGuard (kernel-level)	Secure SSH/web access to containers without exposed ports
Database	MariaDB (shared container)	Single `benchpress-mariadb` container shared across all benches via docker-compose
Cache/Queue	Redis (shared container) + RQ	Single `benchpress-redis` container shared across all benches; RQ for background jobs on host
Real-time	Socket.io via Frappe	Live log streaming during builds and deployments
Routing	iptables DNAT	Routes WireGuard peer IPs to container Docker IPs
Linting	Ruff (Python) + Biome (JS)	Code quality enforcement

Features

Lab Templates -- Define reusable bench configurations with apps, Frappe version (v14, v15, v16, develop), and resource limits
5-Layer Cached Docker Builds -- System deps, SSH config, bench init, app install, and site creation each cached separately. Only changed layers rebuild.
One-Click Deploy -- Background job handles image build, container creation, WireGuard setup, SSH password, and site creation against the shared MariaDB. Admin password is admin for easy access
Live Build & Deploy Logs -- GitHub Actions-style collapsible log viewer with status indicators (success/error/running), streamed in real-time via WebSocket
WireGuard VPN -- Auto-generates keypair, allocates IP from 10.10.0.2-254 pool, adds peer to wg0, configures iptables DNAT routing
Resource Controls -- CPU cores and memory limits per lab, enforced by Docker --cpus and --memory flags
Container Management -- Start, stop, restart, redeploy, and delete benches from the dashboard
Multi-Site Support -- Create multiple Frappe sites per bench container, each with its own set of installed apps
VPN Device Management -- Register persistent devices (Laptop, Mobile, etc.), generate WireGuard configs per device, and manage device lifecycle from a dedicated page
Confirmation Dialogs -- Destructive actions (deploy, stop, delete) require explicit confirmation before execution
Stats Monitoring -- CPU and memory usage polled every 2 minutes from Docker stats API, displayed as progress bars
Connection Info Panel -- Shows VPN IP, SSH command, username, and password with one-click copy to clipboard
Search & Filters -- Filter labs by status, Frappe version, or search by lab ID, title, and app name
Dark Mode -- Toggle between light and dark themes from the sidebar menu

Screenshots

The frontend is a Vue 3 Single Page Application built with Vite, TailwindCSS, and the frappe-ui component library. It features a sidebar navigation with Lucide icons and a clean, professional design.

Labs List (`/frontend/labs`)

Searchable, filterable list of all lab templates. Each row shows the Lab ID, title, Frappe version, status badge (Draft/Building/Ready/Error), memory limit, and CPU cores. Filter by status or Frappe version, or search by lab ID, title, or app name.

New Lab (`/frontend/labs/new`)

Form to create a lab: set Lab ID, title, Frappe version, resource limits (memory, CPU cores), and dynamically add apps with their Git URL and branch.

Lab Detail (`/frontend/labs/:labId`)

Tabbed view with three panels:

Dashboard -- Lab info card, installed apps badges, connection info panel (VPN IP, SSH command, username, password with show/hide toggle and copy-to-clipboard), and container status card with CPU/memory progress bars
Sites -- List of Frappe sites in the bench with create-site dialog (site name + app selection checkboxes)
Build Log -- Collapsible step viewer (GitHub Actions-style) parsing Docker build output into expandable steps with success/error/running indicators

Bench Instances (`/frontend/bench-instances`)

Table of all bench containers showing bench name, lab, Frappe version, status badge (colored: green=Running, orange=Deploying, red=Error/Stopped, gray=Draft), WireGuard IP address, CPU %, and memory %.

Deploy Logs (`/frontend/deploy-logs`)

Select a bench to view its deployment log. Logs are parsed into collapsible phases (e.g., "Building lab image...", "Creating container...", "Configuring WireGuard VPN...") with step-by-step progress indicators.

Build Logs (`/frontend/build-logs`)

Expandable list of image build logs. Click a log entry to reveal the full Docker build output parsed into collapsible steps, each with a colored status dot.

Devices (`/frontend/devices`)

Device management page for registering and managing VPN devices. Users add devices (Laptop, Mobile, etc.) and download WireGuard configuration files per device. Each device gets a persistent VPN identity.

Settings (`/frontend/settings`)

Modal dialog to configure Docker (socket path, base domain, default image, Traefik network), WireGuard (server IP, subnet, port, endpoint, public key), and container resource defaults (memory limit, CPU quota).

Data Model (DocTypes)

BenchPress uses 11 DocTypes to model the complete bench lifecycle:

DocType	Type	Purpose	Key Fields
Lab	Document	Reusable bench template	`lab_id`, `title`, `frappe_version`, `status` (Draft/Building/Ready/Error), `image_tag`, `memory_limit`, `cpu_cores`
Lab App	Child Table	Apps to install in a Lab	`app_name`, `app_label`, `git_url`, `branch`
Bench Instance	Document	Running container	`bench_name`, `lab`, `status` (Draft/Deploying/Running/Stopped/Error), `container_id`, `wg_ip`, `wg_config`, `cpu_usage`, `memory_usage`
Bench App	Child Table	Apps installed in a Bench	`app_name`, `app_label`, `git_url`, `branch`
Bench Site	Document	Frappe site inside a bench	`site_name`, `bench`, `status` (Creating/Active/Inactive/Error), `full_domain`, `admin_password`
Site App	Child Table	Apps installed on a Site	`app_name`, `app_label`
Database Server	Document	Shared MariaDB container	`container_name`, `container_id`, `status`, `port`, `volume_name`, `image_tag`, `memory_limit`
BenchPress Settings	Single	Global configuration	`docker_socket`, `base_domain`, `wg_server_*` keys, `next_wg_ip`, `container_memory_limit`, `container_cpu_quota`
Bench Device	Document	Persistent VPN device	`device_name`, `device_type` (Laptop/Mobile/etc.), `user`, `wg_public_key`, `wg_private_key`, `wg_ip`
Deploy Log	Log	Deployment event log	`bench`, `message`, `log_type`, `timestamp`
Build Log	Log	Image build log	`lab`, `message`, `log_type`, `timestamp`

Entity Relationship

Lab (template)
 |-- Lab App[] (child table: apps to install)
 |
 +---> Bench Instance (deployed container)
        |-- Bench App[] (child table: installed apps)
        |-- Bench Site[] (linked: Frappe sites)
        |    |-- Site App[] (child table: apps on site)
        |-- Deploy Log[] (linked: deployment events)
        |
Lab ----> Build Log[] (linked: image build events)

BenchPress Settings (singleton: global config)

Bench Device (user's registered VPN devices)

API Reference

All endpoints require authentication and use @frappe.whitelist(). Long-running operations are dispatched to background workers via frappe.enqueue() on the "long" queue.

Lab Endpoints

Endpoint	Method	Description
`benchpress.api.get_labs`	GET	List all labs with app count and bench count
`benchpress.api.get_lab`	GET	Get single lab with full apps list
`benchpress.api.build_lab_image`	POST	Enqueue background Docker image build (queue: long, timeout: 3600s)

Note: Lab creation uses createListResource.insert from frappe-ui directly (no custom API endpoint needed).

Bench Endpoints

Endpoint	Method	Description
`benchpress.api.get_benches`	GET	List all benches with CPU/memory stats
`benchpress.api.create_bench`	POST	Create bench from lab template and enqueue deploy
`benchpress.api.bench_action`	POST	Execute action: `start`, `stop`, `restart`, `delete`
`benchpress.api.get_deploy_logs`	GET	Get last 20 deploy log entries for a bench

Site Endpoints

Endpoint	Method	Description
`benchpress.api.create_site`	POST	Create a new site and enqueue setup inside the container

Device Endpoints

Endpoint	Method	Description
`benchpress.api.add_device`	POST	Register a new VPN device (Laptop, Mobile, etc.) and generate WireGuard config
`benchpress.api.remove_device`	POST	Remove a registered VPN device and clean up WireGuard peer
`benchpress.api.list_devices`	GET	List all VPN devices for the current user
`benchpress.api.get_device_wg_config`	GET	Get WireGuard client config for a specific device

System Endpoints

Endpoint	Method	Description
`benchpress.wg_manager.setup_wg_server`	POST	One-time WireGuard server initialization

Note: Settings are accessed via createDocumentResource from frappe-ui (no custom API endpoint needed). Labs, bench instances, sites, and build logs use createListResource / createDocumentResource for native Frappe data fetching.

Bench Instance Document Methods

These are called via frappe.client.run_doc_method on a Bench Instance document:

Method	Description
`enqueue_deploy`	Enqueue deployment as background job (queue: long, timeout: 1800s)
`enqueue_stop`	Stop the container and clean up WireGuard routing
`enqueue_redeploy`	Stop, remove, and redeploy the container from scratch
`enqueue_start`	Start a stopped container

Prerequisites

Before installing BenchPress, ensure your host machine has:

Requirement	Version	Purpose
Frappe Bench	v16	The bench environment to install BenchPress into
Python	3.14+	Backend runtime
Node.js	24+	Frontend build toolchain
Docker Engine	20+	Container management (must be running)
Docker Compose	v2+	Manages shared MariaDB + Redis infrastructure
WireGuard	Any	VPN (`wg` and `wg-quick` commands available)

Note: MariaDB and Redis for bench containers are managed automatically via Docker Compose (benchpress-mariadb and benchpress-redis containers). You only need MariaDB and Redis on the host for Frappe itself.

Required: Docker socket access

The bench user (e.g., frappe) must be in the docker group or you will get a Permission denied error when building images:

sudo usermod -aG docker frappe
# Log out and back in (or run: newgrp docker)

# Verify it works:
docker ps

Common error: PermissionError(13, 'Permission denied') on the Docker socket means the user is not in the docker group. Fix the group membership and restart the bench.

Required: IP forwarding

IP forwarding must be enabled for WireGuard VPN routing between the host and containers:

# Enable immediately
sudo sysctl -w net.ipv4.ip_forward=1

# Make it persistent across reboots
echo "net.ipv4.ip_forward = 1" | sudo tee /etc/sysctl.d/99-benchpress.conf
sudo sysctl -p /etc/sysctl.d/99-benchpress.conf

Required: Passwordless sudo for WireGuard

The bench user needs passwordless sudo for WireGuard commands (used to add/remove VPN peers):

sudo tee /etc/sudoers.d/benchpress-wg > /dev/null <<EOF
frappe ALL=(ALL) NOPASSWD: /usr/bin/wg
frappe ALL=(ALL) NOPASSWD: /usr/bin/wg-quick
EOF
sudo chmod 0440 /etc/sudoers.d/benchpress-wg

Installation

Quick Setup (TL;DR)

cd /path/to/your/frappe-bench
bench get-app https://github.com/Venkateshvenki404224/benchpress --branch develop
bench pip install docker
bench --site your-site.localhost install-app benchpress
bench --site your-site.localhost migrate
bash apps/benchpress/setup.sh your-site.localhost
cd apps/benchpress/frontend && yarn install && yarn build
bench start
# Open http://your-site.localhost:8000/frontend

Detailed Steps

1. Get the app and install dependencies

cd /path/to/your/frappe-bench

# Clone and install BenchPress
bench get-app https://github.com/Venkateshvenki404224/benchpress --branch develop

# Install the Docker Python SDK (required dependency)
bench pip install docker

# Install the app on your site
bench --site your-site.localhost install-app benchpress

# Run migrations to create DocTypes
bench --site your-site.localhost migrate

2. Run the setup script

BenchPress ships with a setup script that handles everything in 6 steps:

cd /path/to/your/frappe-bench
bash apps/benchpress/setup.sh your-site.localhost

The script is idempotent — safe to run multiple times. It will:

Docker group — Add your bench user to the docker group
Shared infrastructure — Start benchpress-mariadb and benchpress-redis containers via docker-compose (generates a random root password, creates the Docker network and volumes, waits for services to be ready)
IP forwarding — Enable via sysctl (runtime + persistent)
Sudoers — Write /etc/sudoers.d/benchpress for passwordless wg and wg-quick
WireGuard tools — Install wireguard-tools if missing
WireGuard server — Generate keys, write wg0.conf, bring up wg0

The script prints the WireGuard Server Public Key you need for BenchPress Settings.

After the script: If the docker group was just added, log out and back in, then bench start.

3. Build the frontend

# Install frontend dependencies and build
cd apps/benchpress/frontend
yarn install
yarn build

# Or use bench build
cd /path/to/your/frappe-bench
bench build --app benchpress

4. Configure BenchPress Settings

Navigate to BenchPress Settings in the Frappe Desk (/app/benchpress-settings)
Set the Docker Socket path (default: unix:///var/run/docker.sock)
Set the Base Domain for your bench instances
Fill in WireGuard (values printed by the setup script):
- WG Server Public Key: (from setup script output)
- WG Server Endpoint: Your server's public IP (curl -s ifconfig.me)
- WG Server Port: 51820

5. Open firewall for WireGuard

sudo ufw allow 51820/udp
sudo ufw reload

Also open UDP 51820 in your cloud provider's security group / firewall if applicable.

For a full WireGuard reference and troubleshooting, see the WireGuard Setup Guide.

Quick start (if you just want the minimum commands):

# Install WireGuard
sudo apt install -y wireguard wireguard-tools

# Allow bench user to run WireGuard/iptables without password
sudo visudo -f /etc/sudoers.d/benchpress
# Add: labs ALL=(ALL) NOPASSWD: /usr/sbin/iptables, /usr/bin/wg, /usr/bin/wg-quick, /sbin/sysctl

# Initialize WireGuard server from Frappe console
bench --site your-site.localhost console
>>> from benchpress.wg_manager import setup_wg_server
>>> setup_wg_server()

# Set your VPS public IP in BenchPress Settings
>>> s = frappe.get_doc("BenchPress Settings")
>>> s.wg_server_endpoint = "YOUR_VPS_PUBLIC_IP"  # run: curl -s ifconfig.me
>>> s.save()
>>> frappe.db.commit()

# Open the firewall port
sudo ufw allow 51820/udp

Note: WireGuard is optional. If not configured, BenchPress still works — containers run normally but without VPN access. Users can connect via Docker bridge IPs on the local machine. See the Local Development section in the guide.

5. Start BenchPress

bench start

Access the dashboard at: http://your-site.localhost:8000/frontend

Usage Workflow

Step 1: Create a Lab

Navigate to Labs > New Lab and configure:

Lab ID: A unique slug (e.g., crm-lab)
Title: Human-readable name
Frappe Version: version-14, version-15, version-16, or develop
Resource Limits: Memory (e.g., 512m, 1g) and CPU cores
Apps: Add apps with their Git URL and branch (e.g., ERPNext from https://github.com/frappe/erpnext, branch version-15)

Step 2: Build the Docker Image

From the Lab Detail page, the image will be built automatically on first deploy, or you can trigger a standalone build. The build uses a 5-layer cached Dockerfile:

System deps (apt: MariaDB, Redis, SSH, WireGuard tools) -- rarely changes
Service config (SSH hardening, sudoers) -- rarely changes
bench init (Frappe framework) -- changes only when Frappe version changes
App install (bench get-app for each app) -- changes when app list changes
Site creation (bench new-site + install-app) -- changes when site/apps change

Build logs stream to the browser in real-time via WebSocket.

Step 3: Deploy a Bench Instance

Click Deploy on the Lab Detail page. The background worker will:

Verify or build the Docker image
Create a container with resource limits on the benchpress Docker network (172.30.0.0/24)
Start the container (MariaDB, Redis, and SSH start automatically via entry.sh)
Generate a WireGuard keypair, allocate a VPN IP (10.10.0.X), add the peer, and configure iptables DNAT routing
Set the SSH password for the frappe user inside the container
Mark the bench as Running

All deployment steps stream to the Deploy Logs page in real-time.

Step 4: Connect via WireGuard

Copy the WireGuard client configuration from the Lab Detail page
Import it into your WireGuard client (available on macOS, Windows, Linux, iOS, Android)
Activate the VPN tunnel

Step 5: SSH and Develop

# SSH into your bench
ssh frappe@10.10.0.X

# Start the Frappe development server
cd frappe-bench
bench start

# Access your Frappe site
# http://10.10.0.X:8000

Step 6: Manage Sites

From the Lab Detail page's Sites tab, create additional Frappe sites inside the running bench. Select which apps to install on each site. Sites can be enabled, disabled, backed up, or dropped.

Development Setup

Clone and set up for development

cd /path/to/your/frappe-bench

# Get the app
bench get-app https://github.com/Venkateshvenki404224/benchpress --branch develop
bench pip install docker
bench --site your-site.localhost install-app benchpress
bench --site your-site.localhost migrate

Frontend development (hot-reload)

cd apps/benchpress/frontend
yarn install
yarn dev

The Vite dev server starts with hot module replacement. The Vue SPA is served at /frontend via the website route rule in hooks.py.

Backend development

# Clear cache after Python/DocType changes
bench --site your-site.localhost clear-cache

# Run migrations after DocType JSON changes
bench --site your-site.localhost migrate

# Run Python linters
cd apps/benchpress
python -m ruff check .
python -m ruff format .

# Run frontend linter
cd frontend
yarn lint

Running tests

bench --site your-site.localhost run-tests --app benchpress

Project Structure

benchpress/
+-- benchpress/
|   +-- api.py                    # REST API layer (~12 endpoints)
|   +-- deploy_manager.py         # Build & deploy orchestration (brain of BenchPress)
|   +-- docker_manager.py         # Docker SDK wrapper (build, create, exec, stats)
|   +-- wg_manager.py             # WireGuard VPN management (keys, peers, routing)
|   +-- device_manager.py         # VPN device registration and config generation
|   +-- stats_collector.py        # Cron job: poll Docker stats every 2 minutes
|   +-- hooks.py                  # App config: routes, scheduler, ignore_links_on_delete
|   +-- mariadb_manager.py        # Shared MariaDB + Redis lifecycle (docker compose)
|   +-- config/
|   |   +-- docker-compose.yml    # Shared infrastructure (MariaDB + Redis)
|   |   +-- mariadb.cnf           # MariaDB custom configuration
|   |   +-- redis.conf            # Redis custom configuration
|   |   +-- .env.example          # Environment variable template
|   |   +-- benchpress-infra.service  # Systemd unit for auto-start on boot
|   +-- lab-templates/
|   |   +-- Dockerfile            # 5-layer cached image build
|   |   +-- scripts/
|   |       +-- entry.sh          # Container entrypoint (starts MariaDB, Redis, SSH)
|   |       +-- install-apps.sh   # Install apps during Docker build
|   |       +-- create-site.sh    # Create site during Docker build
|   |       +-- setup-site.sh     # Create additional sites post-deploy
|   +-- benchpress/
|   |   +-- doctype/
|   |       +-- lab/              # Lab template DocType
|   |       +-- lab_app/          # Lab App child table
|   |       +-- bench_instance/   # Running container DocType
|   |       +-- bench_app/        # Bench App child table
|   |       +-- bench_site/       # Frappe site DocType
|   |       +-- site_app/         # Site App child table
|   |       +-- benchpress_settings/  # Global config singleton
|   |       +-- deploy_log/       # Deployment log DocType
|   |       +-- build_log/        # Build log DocType
|   +-- device_management/
|   |   +-- doctype/
|   |       +-- bench_device/     # VPN device DocType
|   +-- public/
|       +-- images/               # App logos, favicons, Frappe ecosystem app icons
+-- frontend/
    +-- src/
        +-- App.vue               # Root component with sidebar navigation
        +-- router.js             # Vue Router with 9 routes
        +-- socket.js             # Socket.io client for real-time events
        +-- main.js               # App bootstrap with frappe-ui plugins
        +-- theme.css             # Custom theme variables (light + dark)
        +-- pages/
        |   +-- Labs.vue          # Lab list with search, status/version filters
        |   +-- NewLab.vue        # Lab creation form
        |   +-- LabDetail.vue     # Tabbed view: Dashboard, Sites, Build Log
        |   +-- BenchInstances.vue # Bench instance table
        |   +-- DeployLogs.vue    # Deploy log viewer per bench
        |   +-- BuildLogs.vue     # Build log viewer with expandable entries
        |   +-- Devices.vue       # VPN device management page
        |   +-- Settings.vue      # Global settings dialog
        +-- components/
            +-- LogViewer.vue     # Parses logs into collapsible steps
            +-- LogStep.vue       # Single log step with status dot and auto-scroll

Backend File Responsibilities

File	Lines	What It Does
`api.py`	~300	REST API layer with 12 endpoints. All `@frappe.whitelist()`. Long-running ops enqueued to `"long"` queue. Frontend uses `frappe-ui` native data fetching (`createDocumentResource`, `createListResource`) for most reads.
`deploy_manager.py`	~300	Orchestration brain. Coordinates image builds, container creation, WireGuard setup, SSH config, and real-time log streaming.
`docker_manager.py`	~190	Docker SDK wrapper. Builds images, creates/starts/stops containers, executes commands inside containers, collects stats.
`wg_manager.py`	~210	WireGuard VPN management. Generates keypairs, allocates IPs, manages peers, configures iptables DNAT routing for ports 22/8000/9000.
`device_manager.py`	~110	VPN device registration. Creates Bench Device docs, generates WireGuard keypairs, allocates IPs, and builds client configs.
`mariadb_manager.py`	~400	Shared MariaDB + Redis lifecycle via docker-compose. Setup, start, stop, health checks, backups, SQL execution.
`stats_collector.py`	~35	Cron job (every 2 min). Polls Docker stats for running containers, updates CPU/memory fields.
`hooks.py`	~240	App configuration: routes, scheduler events, `add_to_apps_screen`, `ignore_links_on_delete`.

Real-Time Communication

BenchPress uses Frappe's WebSocket system (frappe.publish_realtime) to stream logs to the frontend during long-running operations:

Event	Trigger	Consumer
`bench_deploy_log`	Each deployment step in `deploy_manager.py`	Deploy Logs page, Lab Detail page
`lab_build_log`	Each Docker build line in `deploy_manager.py`	Build Logs page, Lab Detail Build Log tab

Backend pattern:

frappe.publish_realtime("bench_deploy_log", message={
    "bench": bench_name,
    "log": "Starting container...",
    "type": "info"
}, user=frappe.session.user, after_commit=False)

Frontend pattern:

socket.on("bench_deploy_log", (data) => {
    this.logs.push(data);
});

Networking

For complete WireGuard setup instructions, see the WireGuard Setup Guide.

Network	Subnet	Purpose
`benchpress` (Docker bridge)	`172.30.0.0/24`	Internal communication between host and containers
WireGuard (`wg0`)	`10.10.0.0/24`	VPN subnet for user access (server: `10.10.0.1`, clients: `10.10.0.2`-`10.10.0.254`)

Inside-Container WireGuard VPN

Each container runs its own wg0 WireGuard interface. On deploy, BenchPress:

Allocates a VPN IP (e.g., 10.10.0.5) from the 10.10.0.0/24 subnet
Generates a key pair for the container
Adds the container as a peer on the host's WireGuard server
Writes /etc/wireguard/wg0.conf inside the container (peer config pointing back to host via Docker gateway 172.30.0.1)
Runs wg-quick up wg0 inside the container

The result: users connect to the VPN and access the container directly at its allocated IP — no iptables DNAT, no port mapping, no IP-change issues on container restart.

Access	Address	Description
SSH	`ssh user@10.10.0.X`	Direct to container SSH server
Frappe Web	`http://10.10.0.X:8000`	Frappe development server
Socket.io	`http://10.10.0.X:9000`	Real-time events

Shared Infrastructure (Docker Compose)

Managed via benchpress/config/docker-compose.yml with restart: always:

Container	Image	Purpose
`benchpress-mariadb`	`mariadb:10.6`	Shared database for all bench sites. Each site gets its own DB (SHA1-named)
`benchpress-redis`	`redis:7-alpine`	Shared cache (DB 0), queue (DB 1), and socketio (DB 2) for all benches

Container Internals

Each bench container connects to the shared infrastructure over the benchpress Docker network:

Service	Port	Details
SSH Server	22	Started by `entry.sh` on boot
Frappe Web	8000	User runs `bench start`
Socket.io	9000	User runs `bench start`
MariaDB	--	External: `benchpress-mariadb:3306` via Docker DNS
Redis	--	External: `benchpress-redis:6379` via Docker DNS

Supported Frappe Apps

BenchPress works with any Frappe app -- there is no hardcoded app list. When creating a Lab, provide the Git URL and branch for each app you want to install (e.g., ERPNext, HRMS, CRM, LMS, Helpdesk, Wiki, Webshop, or your own custom app).

Tested Configurations

Frappe Version	Base Image	Python	Status
`version-15`	`frappe/build:version-15`	3.11	Tested
`version-16`	`frappe/build:version-16`	3.12+	Planned

Tested v15 apps: Frappe CRM (frappe/crm, branch main)

VPN Device Management

BenchPress supports persistent VPN device registration so users can maintain stable WireGuard identities across sessions:

Register a device -- Navigate to /frontend/devices and add a device with a name and type (Laptop, Mobile, Tablet, Desktop, Other)
Get WireGuard config -- Each device receives a dedicated WireGuard configuration file with its own keypair and IP allocation
Manage devices -- View all registered devices, download configs, or remove devices when no longer needed

Device management uses the Bench Device DocType and is exposed through four API endpoints (add_device, remove_device, list_devices, get_device_wg_config).

Configuration Reference

BenchPress Settings (Singleton DocType)

Field	Default	Description
`docker_socket`	`unix:///var/run/docker.sock`	Docker Engine socket URL
`default_image`	`frappe/bench:latest`	Base Docker image for lab builds
`base_domain`	(required)	Base domain for bench instances
`traefik_network`	`traefik-public`	Docker network for Traefik (if used)
`wg_server_ip`	`10.10.0.1`	WireGuard server IP address
`wg_subnet`	`10.10.0.0/24`	WireGuard VPN subnet
`wg_server_port`	`51820`	WireGuard listen port
`wg_server_endpoint`	(required)	Public IP/hostname for WireGuard clients to connect to
`wg_server_public_key`	Auto-generated	Server's WireGuard public key
`wg_server_private_key`	Auto-generated	Server's WireGuard private key (encrypted)
`next_wg_ip`	`2`	Next IP octet to allocate (auto-increments from 2 to 254)
`container_memory_limit`	`512m`	Default memory limit for containers
`container_cpu_quota`	`100000`	Default CPU quota in microseconds (100000 = 1 core)

Scheduler Jobs

Schedule	Function	Description
Every 1 minute	`benchpress.stats_collector.collect_all_stats`	Polls Docker and WireGuard stats, updates CPU/memory metrics and VPN transfer counters
Every 5 minutes	`benchpress.mariadb_manager.scheduled_health_check`	Checks shared MariaDB health, attempts restart if down
Daily at 2 AM	`benchpress.mariadb_manager.scheduled_backup`	Full MariaDB backup with 7-day retention

Contributing

Fork the repository
Create a feature branch from develop: git checkout -b feature/my-feature
Make your changes following Frappe coding conventions
Run tests: bench --site your-site.localhost run-tests --app benchpress
Run linters: cd apps/benchpress && python -m ruff check . && python -m ruff format .
Commit using Conventional Commits: feat(lab): add batch deploy support
Push and open a Pull Request against develop

Commit Format

type(scope): short description

feat(lab):     add multi-app selection to lab creation form
fix(deploy):   prevent duplicate container on rapid double-click
refactor(wg):  migrate iptables rules to nftables
test(api):     add tests for site creation endpoint
docs(readme):  add architecture diagram
chore(deps):   bump frappe-ui to 0.1.192

License

MIT License. See LICENSE for details.

Built for FOSS Hack 2026 by Venkatesh

Powered by Frappe Framework

GitHub Repository

Name		Name	Last commit message	Last commit date
Latest commit History 106 Commits
.github		.github
benchpress		benchpress
docs		docs
e2e		e2e
frontend		frontend
.editorconfig		.editorconfig
.eslintrc		.eslintrc
.gitignore		.gitignore
.pre-commit-config.yaml		.pre-commit-config.yaml
ARCHITECTURE.md		ARCHITECTURE.md
CODE_OF_CONDUCT.md		CODE_OF_CONDUCT.md
CONTRIBUTING.md		CONTRIBUTING.md
README.md		README.md
SECURITY.md		SECURITY.md
license.txt		license.txt
package-lock.json		package-lock.json
package.json		package.json
pyproject.toml		pyproject.toml
setup.sh		setup.sh

Folders and files

Latest commit

History

Repository files navigation

BenchPress

What is BenchPress?

Table of Contents

Detailed Guides

The Problem

The Solution

Architecture

How the Pieces Fit Together

Container Lifecycle

Tech Stack

Features

Screenshots

Labs List (/frontend/labs)

New Lab (/frontend/labs/new)

Lab Detail (/frontend/labs/:labId)

Bench Instances (/frontend/bench-instances)

Deploy Logs (/frontend/deploy-logs)

Build Logs (/frontend/build-logs)

Devices (/frontend/devices)

Settings (/frontend/settings)

Data Model (DocTypes)

Entity Relationship

API Reference

Lab Endpoints

Bench Endpoints

Site Endpoints

Device Endpoints

System Endpoints

Bench Instance Document Methods

Prerequisites

Required: Docker socket access

Required: IP forwarding

Required: Passwordless sudo for WireGuard

Installation

Quick Setup (TL;DR)

Detailed Steps

1. Get the app and install dependencies

2. Run the setup script

3. Build the frontend

4. Configure BenchPress Settings

5. Open firewall for WireGuard

5. Start BenchPress

Usage Workflow

Step 1: Create a Lab

Step 2: Build the Docker Image

Step 3: Deploy a Bench Instance

Step 4: Connect via WireGuard

Step 5: SSH and Develop

Step 6: Manage Sites

Development Setup

Clone and set up for development

Frontend development (hot-reload)

Backend development

Running tests

Project Structure

Backend File Responsibilities

Real-Time Communication

Networking

Inside-Container WireGuard VPN

Shared Infrastructure (Docker Compose)

Container Internals

Supported Frappe Apps

Tested Configurations

VPN Device Management

Configuration Reference

BenchPress Settings (Singleton DocType)

Scheduler Jobs

Contributing

Commit Format

License

About

Resources

License

Code of conduct

Contributing

Security policy

Labs List (`/frontend/labs`)

New Lab (`/frontend/labs/new`)

Lab Detail (`/frontend/labs/:labId`)

Bench Instances (`/frontend/bench-instances`)

Deploy Logs (`/frontend/deploy-logs`)

Build Logs (`/frontend/build-logs`)

Devices (`/frontend/devices`)

Settings (`/frontend/settings`)

Packages
