UML-MCP: Diagram Generation via MCP

Generate UML and other diagrams from AI assistants via the Model Context Protocol. Supports 30+ diagram types through Kroki, PlantUML, Mermaid, and D2.

Live: MCP endpoint | Add via Smithery

Features

• 30+ diagram types -- UML (Class, Sequence, Activity, Use Case, State, Component, Deployment, Object), Mermaid, D2, Graphviz, TikZ, ERD, BlockDiag, BPMN, C4, and more via Kroki
• MCP integration -- works with Cursor, Claude Desktop, and any MCP client
• Multiple output formats -- SVG, PNG, PDF, JPEG, base64 (varies by diagram type)
• Automatic fallback -- Kroki first, then PlantUML server or Mermaid.ink if unavailable
• Read-only mode -- MCP_READ_ONLY=true disables file writes (URL + base64 only)
• Flexible deployment -- stdio, HTTP, Vercel serverless, Docker, or Smithery

Quick start

Install

# Via Smithery (one command)
npx -y @smithery/cli install antoinebou12/uml --client claude

# Or manually
git clone https://github.com/antoinebou12/uml-mcp.git && cd uml-mcp
uv sync            # recommended
# poetry install   # alternative
# pip install -e . # alternative

The published package installs mcp_core and tools only. The ai_uml/ tree remains in the repository for research; it is not part of the installable distribution.

Run

# MCP stdio transport (default)
uv run python server.py

# HTTP transport
uv run python server.py --transport http --port 8000

# List tools and exit
uv run python server.py --list-tools

MCP client config

Copy the appropriate snippet from config/ into your client:

• Cursor: config/cursor_config.json
• Claude Desktop: config/claude_desktop_config.json

Replace /path/to/uml-mcp with the actual path. See config/README.md for config file locations.

Supported diagram types

Category	Types
UML (PlantUML)	Class, Sequence, Activity, Use Case, State, Component, Deployment, Object
General	Mermaid, D2, Graphviz, ERD, BlockDiag, BPMN, C4
Specialized	TikZ, Excalidraw, Nomnoml, Pikchr, Structurizr, SVGBob, WaveDrom, WireViz, and more

Full list with supported output formats: run python server.py --list-tools or query uml://formats.

MCP tools and resources

Tools:

• generate_uml -- generate a diagram and optionally save to disk
• generate_diagram_url -- return diagram URL + base64 without file writes
• validate_uml -- structural validation before render (no network by default)

Resources (via uml:// URIs): types, templates, examples, formats, capabilities, server-info, mermaid-examples, bpmn-guide, workflow

Deployment

Vercel

The repo includes vercel.json pre-configured for serverless deployment:

1. Connect this repo to Vercel
2. Your MCP URL: https://<project>.vercel.app/mcp (use /mcp path, not root)
3. Vercel uses read-only filesystem -- diagrams are returned as URLs/base64

Smithery

After deploying to Vercel:

1. Go to smithery.ai/new, choose URL
2. Enter https://<project>.vercel.app/mcp
3. Set display name, description, and homepage in Settings

See docs/integrations/vercel_smithery.md for detailed instructions and troubleshooting.

Docker

docker compose up -d          # full stack with Kroki + PlantUML
# or standalone:
docker build -t uml-mcp . && docker run -p 8000:8000 uml-mcp

Configuration

Variable	Description	Default
KROKI_SERVER	Kroki server URL	https://kroki.io
PLANTUML_SERVER	PlantUML server URL	http://plantuml-server:8080
MCP_OUTPUT_DIR	Diagram output directory	./output
MCP_READ_ONLY	Disable file writes	false
MCP_MAX_CODE_LENGTH	Max diagram code length	500000
USE_LOCAL_KROKI	Use local Kroki instance	false
USE_LOCAL_PLANTUML	Use local PlantUML instance	false

Full options: docs/configuration.md

Architecture

server.py              -- MCP entry point (stdio/HTTP)
app.py                 -- FastAPI REST API + MCP HTTP at /mcp
api/app.py             -- Vercel serverless wrapper
mcp_core/
  core/                -- config, server, CLI, utilities, diagram pipeline
  tools/               -- generate_uml, generate_diagram_url, validate_uml
  prompts/             -- diagram generation prompts
  resources/           -- uml:// resource handlers
tools/kroki/           -- Kroki, PlantUML, Mermaid, D2 clients
ai_uml/                -- research code in the repo only; **not** shipped in the PyPI wheel (see docs/ai_uml.md)

Fallback strategy: Kroki (primary) -> PlantUML server (UML types) / Mermaid.ink (Mermaid) -> error with details.

Development

# Install dev dependencies
uv sync --all-groups

# Run tests
uv run pytest tests/ -v

# Lint
uv run ruff check . && uv run ruff format --check .

# Integration tests (requires real FastMCP)
USE_REAL_FASTMCP=1 uv run pytest tests/integration -v

# Local CI
make ci

Documentation

Built with MkDocs + Material:

• Online: antoinebou12.github.io/uml-mcp
• Local: uv run mkdocs serve then open http://127.0.0.1:8000

Contributing

• Contributing guide
• Code of conduct
• Security policy

License

MIT

Acknowledgements

PlantUML | Kroki | Mermaid | D2
